EV3285 FlexScan

The EV3285 is perfectly suited for professional applications, thanks to 4K Full HD resolution. A USB-C port provides for lightning fast data transfer speeds and allows you to charge devices like tablets and notebooks.

  • 80 cm (31.5")
  • 3840 x 2160 (4K UHD)
  • 16:9 Aspect ratio
    Farbe wählen:
Product image EV3285-BK FlexScan
Product image EV3285-WT FlexScan

Image quality

Precise, high-contrast, bright and crisp screen

4K resolution for ultra-sharp texts and images

Be it CAD, office, or video applications, the FlexScan EV3285 with its 4K ultra HD resolution supports your work with its extraordinary display quality. Thanks to a native resolution of 3840 x 2160 (4K UHD) pixels and 140 ppi (pixels per inch), the 31.5 monitor presents texts and graphics clearer and more precisely than ever before.


Maximum image quality thanks to the IPS panel

The monitor is capable of all three key elements of excellent image quality: excellent resolution of 3840 x 2160 (4K UHD) pixels, maximum contrast of 1300:1, and stable brightness of up to 350 cd/m². That means you will experience razor-sharp text contours, brilliant graphics, and clear images. Thanks to the high-quality IPS panels with LED backlight, contrasts and colours remain stable from every viewing angle.


Precise color control

An image can only be perfect if the colours are, too. This is why EIZO monitors have a 10-bit look-up table at a minimum, which allows the colour information to be assigned much more precisely than with conventional 8-bit LUTs. The finest colour gradations ensure that gradients are always perfectly displayed, while also offering customised adjustment options. For example, you can adjust the white balance from 4000 K to 10 000 K in 500-K intervals.

Overdrive to quickly change images

Fast, faster, overdrive. The overdrive function accelerates switching time so that the gray-gray change takes only 5 ms on average. You can watch films and rapidly changing images without annoying afterglow.

Variety of ports

Best connectivity

Cutting-edge connectivity with USB-C

A single USB-C cable is all that is needed to provide video and audio reproduction, transfer data quickly and supply power to the connected devices. The 60 W power supply via USB-C is highly practical and can reliably charge small computers or laptops. This creates more space on your desk since you no longer need an additional power supply for your computer.

The monitor is compatible with the following USB-C devices.



One monitor, many ports

It couldn't be easier: Most end devices, such as PC, laptop, mouse, keyboard or headphones, can be connected directly to the monitor, thanks to its wide range of signal interfaces and ports. This makes your daily work easier and ensures a tidy desk.

Design

A pleasing sight on any desk

Elegant design

The monitor’s appearance can be the key to creating a pleasant working atmosphere. Whether you are at home or in the office, the monitor’s virtually frameless design and ergonomic functionality allows it to fit naturally into your workplace environment. The housing is available in both an elegant black and in white, with matching white cables.

[Translate to English:] FlexScan Ultraslim design

Controls integrated into bezel

Electrostatic switches are integrated into the front of the EV3285 instead of mechanical buttons. This ensures ease of use while also giving the monitor an extremely elegant look. The speakers and all the controls are also built into the bezel, pointing forward in the direction of the user. They are fully integrated into the monitor’s flat, nearly frameless design to offer an excellent user experience.


Software and ease of use

Features for greater comfort

Picture-by-picture: everything at a glance

If multiple computers are connected with the monitor, picture-by-picture mode allows you to view different signal sources on the screen independently. This saves time and means you don’t have to switch constantly between different video and audio sources.

Pre-set picture-by-picture layouts are available at the push of a button, allowing you to comfortably display multiple applications in different sizes.

Picture-in-Picture

Picture-in-Picture mode allows you to display two image signals at the same time – a main image and a reduced-scale image from another signal source inserted into the main image. The size and position of the second window can be varied.


Preset color modes: optimized display at the touch of a button

Pre-set color modes optimise the viewing of images, texts or films. Because it makes a difference whether you are watching a film, editing a picture, surfing the net, or writing texts. At the touch of a button, you set the respective pre-set for brightness, gamma correction and colour temperature. For example, the Paper mode simulates the pleasant contrast of printed paper, which is easy on the eyes when reading and prevents fatigue.


Operation made easy thanks to the Button Guide

With the Button Guide, you have all functions at a glance. One touch of the control panel is enough, and the function assignment of the buttons is displayed. Your advantage: clarity of operation and a clean, uncluttered design.

Screen InStyle

In addition to the on-screen menu, you can conveniently control the EV3285 by using the Screen InStyle software on a Windows PC. The configuration options include color reproduction, energy saving options, and ergonomic functions. In multi-screen systems, the settings can be applied synchronously to all connected screens with Screen InStyle.

System administrators can centrally manage and control monitors connected in the network with Screen InStyle installed using the Screen InStyle Server application. This optimises power consumption and simplifies asset management of the monitors.

Company-wide default setup

Monitor Configurator

Workload reduction for administrators: The software allows you to create a default setup for all relevant monitor settings. This setup can be distributed to the connected monitors via the local network which facilitates the roll-out process.


Ergonomics

Working in a relaxed manner

Save electricity and your eyes with Auto EcoView

At day, at night, bright, dark: No matter when and how you work, the Auto EcoView function continuously measures changes of the ambient light and optimises the monitor with ideal brightness values automatically by using a sensor. The benefits: Annoying glare is reduced, your eyes will not get tired as quickly. A special two-point control takes into account the brightest and darkest environment over the course of the day with the respectively desired screen brightness. Another advantage: Thanks to the automatic brightness adjustment, you will save up to 50% of your electricity costs in comparison to a monitor that is permanently operated at maximum brightness.

Of course, you can also continue to configure the monitor manually. EcoView Index is used for orientation on how environmentally friendly and economical your settings are.

For the sake of the eyes

Flicker free

To help protect your eyes, EIZO has developed a hybrid technology to control the backlight. This combines the benefits of the otherwise standard PWM (pulse width modulation) and DC (direct current) control. The PWM control uses much higher frequencies than standard PWM methods. The result: a flicker-free viewing experience while maintaining picture quality and colour stability. In addition, compared to pure DC control, you can adjust the brightness to less than 1% of the maximum value in darkly lit rooms. The benefit: Your screen remains free from glare even under these conditions.

The flicker-free and low blue light content of the EIZO FlexScan monitors is certified by TÜV Rheinland.

Anti-glare coating: more image, less reflection

The EV3285 offers a perfect, non-glare surface. By minimising glare by diffusing the reflected light, the EV3285 effectively protects your eyes from straining. This keeps your eyes from getting as tired and allows you to sit comfortably in front of the monitor, without having to sit in a forced position to prevent glare.


Flexible stand

Ergonomic and stable: the adjustable stand focuses on ergonomics. You can rotate, swivel and tilt the monitor stand until you find the most comfortable setting for your back, neck and sitting posture. It features continuous height adjustment and can be lowered almost to the base plate of the stand, enabling you to position the top image line ergonomically right below your eye level.

Height

149 mm

Tilt

Between 5° forwards and 35° backwards

Swivel

344°

Sustainability

Environmentally and socially conscious production

EcoView Optimizer

Save up to 30% of energy

Save electricity without compromising quality: The EcoView Optimizer reduces the background lighting fully automatically for dark images. This reduces electricity consumption by up to 30%. At the same time, the signal is amplified and the color tone values adjusted. The result: You will enjoy the image quality you are used to but consume less power.


Zero-watt consumption thanks to the power switch

The monitors have an integrated mechanical power switch, which is extremely practical and energy-saving: If you switch off the monitor using the power switch, the device will stop consuming any power at all. Moreover, it consumes a maximum of 0.5 watt in standby mode.

Socially responsible production

The EV3285 is produced in a socially responsible way. It is free of child labour and forced labour. Suppliers along the supply chain have been carefully selected and they have also committed themselves to produce in a socially responsible way. This applies in particular to conflict minerals. We present a detailed report about our social responsibility annually and voluntarily.


Environmentally and climate friendly

Each EV3285 is manufactured in our own factory, which implements an environmental management system in accordance with ISO 14001. This includes measures to reduce waste, wastewater and emissions, resource and energy consumption, as well as to encourage environmentally conscious behaviour among employees. We publicly report on these measures on an annual basis.


Warranty

Highest investment security

Five-year warranty

EIZO grants a five-year warranty. This is possible thanks to the highly developed production process based on a simple principle of success: sophisticated and innovative technology, made from high-end materials.


Technical data

General
Item no.
EV3285-BK
EV3285-WT
Case colour
Black
White
Solution area Office
Product line FlexScan
Areas of application Large and medium-sized companies, Private user & small business, Home Office, CAD, Finance, Control rooms
EAN
4995047051893
4995047051909
Display
Screen size [in inches] 31.5
Screen size [in cm] 80
Format 16:9
Viewable image size (width x height) 697 x 392
Ideal and recommended resolution 3840 x 2160 (4K UHD)
Pixel pitch [mm] 0.181 x 0.181
Pixel density [in ppi] 140
Resolution supported 3840 x 2160 (4K UHD), 2560 x 1440, 1920 x 1200, 1920 x 1080 (Full HD), 1680 x 1050, 1600 x 1200, 1280 x 1024, 1024 x 768, 800 x 600, 720 x 400, 640 x 480
Panel technology IPS
Max. viewing angle horizontal 178
Max. viewing angle vertical 178
Number of colours or greyscale 16.7 million colors (DisplayPort, 8 Bit), 16.7 million colors (HDMI, 8 Bit), 16.7 million colors (USB-C, 8 Bit)
Colour palette/look-up table More than 1.06 billion color tones /14-bit
Max. colour space (typical) sRGB (100%)
Max. brightness (typical) [in cd/m²] 350
Max. dark room contrast (typical) 1300:1
Response time grey-grey alternation (typical) [in ms] 5
Reaction time black-white-black-change (typical) 14
Max. refresh rate [in hertz] 60
Backlight LED
Features & Operation
USB-C docking
Preset colour/greyscale modes 2x manual memory locations, sRGB, Paper, Movie, DICOM
DICOM tone curve
Auto EcoView
EcoView Index
EcoView Optimizer
Overdrive
No flickering thanks to hybrid controls
Signal range extension (HDMI)
HDCP Decoder
Input signal identification
Picture-by-Picture
Built-in speakers
OSD language de, en, fr, es, it, se
OSD setting options Color Mode, Brightness, Contrast, Color temperature/White point, Gamma, Overdrive, Colour tone, Color saturation, Picture-by-Picture, Resolution, Scaling, Image position, OSD language, Signal input, All EcoView functions, Volume
Button Guide
Integrated power unit
Connections
Video Input 2x HDMI (HDCP 1.4/2.2; 4K @ 60Hz), USB-C (DisplayPort Alt Mode, HDCP 1.3), DisplayPort (HDCP 1.3)
USB specification USB 5Gbps (USB 3)
USB upstream ports 1 x type C (DisplayPort Alt Mode, 60 W max.)
USB downstream ports 2 x type A (1 x 10.5 W battery charging function)
Video signal USB-C, DisplayPort, HDMI (RGB, YUV)
Audio input USB-C, DisplayPort, HDMI
Audio output 3.5 mm stereo jack
Electrical data
Frequency USB-C: 31-134 kHz, 29-31 Hz/59-61 Hz; DisplayPort: 31-134 kHz, 29-31 Hz/59-61 Hz; HDMI: 31-135 kHz, 29-31 Hz/49-51 Hz/59-61 Hz
Power consumption (typical) [in watt] 33
Maximum Power Consumption [in watt] 163 (at maximum brightness with all signal inputs and USB ports in use)
Power Save Mode [in watt] 0.5
Power consumption off [in watt] 0
Energy efficiency class G
Energy consumption/1000h [in kWh] 34
Power supply AC 100-120 V / 200-240 V, 50/60 Hz
Power supply via USB C 60
Power management
Dimensions & Weight
Dimensions [mm] 717 x (427 - 576) x 230
Weight [in kilograms] 11
Dimensions without stand [mm] 717 x 416 x 51,5
Weight without stand [in kilograms] 7.6
Link technical drawing Dimension drawing (PDF)
Swivel 344
dimensionTilt 5 / 35
Height adjustment range [mm] 149
Hole spacing 100 x 100
Certification and standards
Certification CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 8, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC, EAC
Software & Accessories
Software Screen InStyle
Additional supply Signal cable HDMI - HDMI, USB/signal cable (USB-C - USB-C), Signal cable DisplayPort - DisplayPort, Manual via download, Power cord, Quick guide
Accessories PM200-K, CC100, PCSK-03
Warranty
Warranty duration 5 years for unit and LCD module up to 30,000 operating hours, whichever comes first.
Included warranty service Zero pixel defects guarantee; no fully illuminated sub-pixels (sub-pixels ISO 9241-307) for six months from date of purchase.

Downloads & Service

Around your product

Manuals & Documents

Manual - EV3285

Datasheet - EV3285

PDF | 11 MB

Product images EV3285-BK

ZIP | 5 MB

Product images EV3285-WT

ZIP | 4 MB

EIZO DuraVision and FlexScan solutions for control rooms

PDF | 1 MB

FlexScan brochure

PDF | 5 MB

FlexScan Product overview

PDF | 808 KB

Software

Device driver - EV3285

Monitor Configurator

Software for network-wide settings.

Monitor Test

Test the properties and parametres of your monitor quickly and easily with software developed in-house at EIZO.

Screen InStyle / Server

With Screen InStyle, power, colour, brightness and other settings can be easily managed. Screen InStyle Server allows system administrators to manage and control monitors and PCs connected to the network.

FAQs

EIZO monitors generally have two or more signal inputs. You can easily switch between two or more computers by pressing a button on the front of the monitor. For devices with KVM switch functionality, the USB hub also switches to the respective computer at the same time.

This may be a problem with the graphics card driver. Please install the latest driver for your graphics card and restart the PC with the monitor.
Older graphics cards may not be able to display this resolution. In this case, you will require a new graphics card with the matching output.

Firstly, please check the resolution of the LCD screen. Check the recommended resolution stated for the respective LCD screen. If you have set a lower resolution than recommended, this may result in blurring.

The LCD display is comprised of a fixed number of image elements (pixels), which light up to display the contents of the screen. The image is comprised of horizontal and vertical pixels. LCDs achieve the best image quality if all pixels can be allocated data, i.e. if the resolution configured on the computer corresponds to that of the LCD display.

The color temperature is a benchmark for measuring the white tone and is stated in Kelvin. At high temperatures, the white tone appears slightly blue, while it has a more red tone at low temperatures.
5000 K: Often used in the printing industry.
6500 K: Suitable for displaying photos and video images.

The color tone rendering is relative to the change of the input signal level. This relationship is generally known as the gamma characteristic. In image reproduction, low gamma values result in white images and high gamma values result in high-contrast images.

International standard for an RGB color space. A color space has been defined, which most devices can comply with, to enable color matching between various applications and devices, such as monitors, scanners, and digital cameras. sRGB images, which are detected or issued on "sRBG devices" are limited to the full sRBG color range and no colors outside the sRBG color space. Color allocation, white point, and gamma are permanently defined.

In connection with a USB-compatible computer, the monitor acts as a hub, to which other USB-compatible peripherals can be connected.

The viewing angle relates to the angle, beneath which the contrast is better than 10:1. These are normally values of 160° to 178°. These values do not provide any information about what enormous differences in contrast may result within the viewing angle. The contrasts should not change significantly for users with a perpendicular view and a slightly side-on view. It must not make a difference whether the viewer is looking at the middle of the image or the edge of the image. How much the contrast stability varies with different LCD technologies is best checked using a measurement diagram or by a direct visual comparison. The more stable the contrast in the user's viewing frustum, the better the image rendering.

High Definition Multimedia Interface. Interface to transfer digital audio and video data
